Complete Plastic Ring + Nylon Bag Filter Assemblies for Standard Housings
Skytech Ultrafab Plastic Ring & Nylon Bags are complete, ready-to-install filter bag assemblies combining a polypropylene or nylon retaining ring with a precision-woven nylon mesh or felt bag body. The ring-and-bag assembly installs directly into any standard P1 or P2 bag filter housing in seconds — with the ring providing the positive housing seal and the nylon bag delivering accurate, reusable particle separation across the full range of industrial liquid filtration applications.
What Is a Plastic Ring & Nylon Bag Assembly?
A Plastic Ring & Nylon Bag is a two-component filter element where a rigid polypropylene or nylon plastic ring — machined or moulded to P1 or P2 standard dimensions — is permanently joined to a nylon mesh or nylon felt filter bag. The ring seals against the filter housing basket seat to prevent bypass of unfiltered liquid around the bag edge, while the nylon bag body provides the filtration surface. The assembly is the standard disposable or reusable filter element for paint, ink, adhesive, resin, and chemical liquid bag filtration.
Technical Specifications
| Parameter | Details |
|---|---|
| Ring Material | Polypropylene (standard) or Nylon |
| Bag Material | Nylon Monofilament Mesh or Nylon Needle-Felt |
| Micron Range (Mesh) | 25 µm – 1500 µm |
| Micron Range (Felt) | 1 µm – 100 µm |
| Ring Sizes | P1 (Size 1) and P2 (Size 2) — ISO standard |
| Max Temperature | 120°C (nylon) |
| pH Range | 4 – 12 |
| Reusability (Mesh) | 50–100 cleaning cycles |
Applications
- Paint and Coatings: Straining of solvent-borne and water-borne paints to remove pigment agglomerates, skin, and coarse contamination — nylon mesh bags reused many times for economy
- Adhesives: Removal of gel particles, polymer lumps, and coarse contamination from hot-melt and water-based adhesive lines before dispensing or filling
- Resin Systems: Filtration of epoxy, polyurethane, and polyester resin systems prior to metering, mixing, and moulding operations
- Food and Beverage: Coarse straining of syrups, sauces, juice, and liquid food ingredients — nylon is FDA-compliant for food-contact applications within its operating pH range
- Chemical Processing: General chemical liquid straining and pre-filtration in industrial bag filter housings where nylon chemical resistance covers the process fluid chemistry
Why Choose Skytech Ultrafab for Plastic Ring & Nylon Bags?
- Complete Assembly, No Build-Up: Ring and bag supplied as a complete assembly — no on-site joining, alignment, or assembly required. Install and operate immediately on arrival
- Two Filtration Modes: Mesh bags for reusable surface filtration (paint, adhesive, resin); felt bags for depth filtration with higher dirt-holding capacity — choose by application from the same ring platform
- Reuse Economy: Nylon mesh versions cleaned and reused 50–100 cycles — 60–80% reduction in filter consumable cost versus disposable felt bag alternatives for suitable applications
- Universal Housing Fit: P1 and P2 ring dimensions fit all standard bag filter housings — no housing modification or adaptor required for any major brand
- Fast Delivery: Standard sizes and micron ratings in stock for same-week dispatch — mesh and felt options both available from ready stock for immediate replacement needs
